Wet chemical Processes
◆ Single wafer wet etcher

Machine: DNS SPW812
Application: Metal etching

•Substrate size: 6”.

•Capacity: 10k pieces/month




◆ Electrical platter

Machine: Cu platter
Application: Cu plating

•Substrate size: 6”.

•High uniformity Cu plating was achieved.
•EP thickness: 5um~10um
•Uniformity < ± 10% (Thickness 10um)
•Capacity: 10k pieces/month




◆ P.R. stripper

Machine: Kaijo bocket cleaner
Application: P.R. stripping

•Substrate size: 6".

•Capacity: 10k pieces/month




◆ Wafer Scrubber

Machine:DNS 629 scrubber
Application: Wafer surface cleaning

•Substrate size: 6".

•Bruch clean
•High pressure D.I. beam clean
•Capacity: 10k pieces/month




◆ Electro-less plating systems

Machine: ENIG platter
Application:
1.Ni(2.5~6um)/ Fresh Gold(0.05~0.1um) electro-less plating
2.Ni(2.5~6um)/ Thick Gold(0.4~0.5um) electro-less plating
3.Ni(2.5~6um)/ Pd(0.1~0.3um) /Fresh Gold(0.05~0.1um) electro-less plating

•High uniformity and high stability electro-less plating was achieved.

•Ni/Au on Ag, Ag-Pt, Ag-Pd, Cu were achieved.
•Substrate type: Si, Glass, Ceramic, LTCC substrate.
•Uniformity < ± 10%
•Capacity: 10k pieces/month
